SKU : B-20CR
ECOVISION Series
หมวดหมู่ : 12. Lab Equipment , Microscope , EDUCATIONAL Microscopes , Biological Microscopes , OPTIKA , Microscopes ,
แบรนด์ : OPTIKA
Share
Head: Monocular, 45° inclined; 360° rotating.
Eyepiece: WF10x/18 mm, secured by screw.
Nosepiece: Triple ball bearings revolving nosepiece, reversed.
Objectives:
Achromatic 4x/0.10, W.D. 27.2 mm.
Achromatic 10x/0.25, W.D. 7.4 mm.
Achromatic 40x/0.65, W.D. 0.6 mm.
All with anti-fungus treatment.
Specimen stage: Double layer, 105×95 mm, xy moving range 50×15 mm.
Focusing: Coaxial coarse and fine focusing mechanism with limit stop to prevent the contact between objective and specimen.
Condenser: N.A. 0.65 with iris diaphragm.
Illumination: 0.5 W LED, with brightness control, rechargeable batteries (not included).
Color temperature: 6,300 K. 100-240Vac/5Vdc external power supply.
Related Literature:
OPTIKA - B-20CR - Technical Datasheet EN - 226.48 KB
https://www.optikamicroscopes.com/optikamicroscopes/product/b-20cr/
