BS.1153-PLi/4N bScope trinocular microscope

bScope series - Brightfield
bScope trinocular microscope, HWF 10x/20 mm eyepieces and quadruple nosepiece with plan PLi 4/10/S40/S100x oil infinity corrected IOS objectives, 131 x 152/197 mm stage with integrated mechanical 75 x 36 mm rackless X-Y stage. 3 W NeoLED Köhler illumination and integrated power supply. Supplied without
rechargeable batteries

Model : BS.1153-PLi/4N

• HWF 10x/20 mm eyepieces

• Trinocular head, Siedentopf type, 30° inclined swiveling tubes. Interpupillary distance 48-76 mm. Diopter adjustments on both tubes

• Reversed quadruple revolving nosepiece on ball-bearings

• Plan PLi 4x, 10x, S40x, S100x oil immersion infinity corrected IOS objectives

• All optics are anti-fungus treated and anti-reflection coated for maximum light throughput

• Coaxial coarse and fine adjustments with 180 graduations. Precision 1.1 μm, 0.2 mm per rotation. Total travel approximately 19 mm. Friction adjustment Plain 131 x 152/197 mm rackless stage with 75 x 36 mm mechanical rackless stage Height adjustable Abbe color coded condenser N.A. 1.25 with iris diaphragm and
  filter holder 3 W NeoLED Köhler illumination. Internal power supply 100-240 V (CE)

• Supplied with power cord, dust cover, 5 ml immersion oil in styrofoam case and without rechargeable AA-type batteries

ACCESSORIES

Eyepieces
BS.6010 HWF 10x/20 mm eyepiece for bScope, Ø 23 mm tube	BS.6010-P HWF 10x/20 mm eyepiece with pointer for bScope, Ø 23 mm tube	BS.6010-C HWF 10x/20 mm eyepiece with cross hair for bScope, Ø 23 mm tube	BS.6010-CM HWF 10x/20 mm eyepiece with 10/100 micrometer and cross hair for bScope, Ø 23 mm
BS.6012 BS.6012 WF 12.5x/14 mm eyepiece for bScope, Ø 23 mm tube	BS.6015 WF 15x/12 mm eyepiece for bScope, Ø 23 mm tube	BS.6020 WF 20x/11 mm eyepiece for bScope, Ø 23 mm tube	BS.6099 Pair of eyecups for BS.6010 and BS.6020
BS.6099-S Pair of eyecups for BS.6012, BS.6015	BS.6310 WF 10x/22 mm eyepiece for bScope Materials Sciences and fluorescence models with Ø 30 mm tube	BS.6310-M WF 10x/22 mm eyepiece with 10/100 micrometer for bScope Materials Sciences and fluorescence models with Ø 30mm tube	BS.6315 WF 15x/12 mm eyepiece for bScope Materials Sciences, and fluorescence models with Ø 30 mm tubes
BS.6399 Pair of eyecups for bScope Materials Sciences, Ø 30 mm tube
E-Plan objectives
BS.7104 E-plan EPL 4x/0.10 objective. Working distance 37.0 mm	BS.7110 E-plan EPL 10x/0.25 objective. Working distance 6.61 mm	BS.7120 E-plan EPL 20x/0.40 objective. Working distance 1.85 mm	BS.7140 E-plan EPL S40x/0.65 objective. Working distance 0.64 mm
BS.7160 E-plan EPL S60x/0.85 objective. Working distance 0.20 mm	BS.7100 E-plan EPL S100x/1.25 oil immersion objective. Working distance 0.19 mm
Plan objectives
BS.7202 Plan PL 2.5/0.05 objective. Working distance 37.0 mm	BS.7204 Plan PL 4x/0.10 objective. Working distance 37.0 mm	BS.7210 Plan PL 10x/0.25 objective. Working distance 17.9 mm	BS.7220 Plan PL 20x/0.40 objective. Working distance 8.8 mm
BS.7240 Plan PL S40x/0.65 objective. Working distance 8.6 mm	BS.7260 Plan PL S60x/0.85 objective. Working distance 0.25 mm	BS.7200 Plan PL S100x/1.25 oil immersion objective. Working distance 0.33 mm	BS.7400 Plan Fluarex PLFi S100x/0,90 IOS oil-immersion objective. Working distance 0.13 mm
E-Plan IOS objectives
BS.8204 E-plan EPLi 4x/0.10 infinity corrected IOS objective. Working distance 18.9 mm	BS.8210 E-plan EPLi 10x/0.25 infinity corrected IOS objective. Working distance 5.95 mm	BS.8220 E-plan EPLi 20x/0.40 infinity corrected IOS objective. Working distance 2.61 mm	BS.8240 E-plan EPLi S40x/0.65 infinity corrected IOS objective. Working distance 0.78 mm
BS.8200 E-plan EPLi S100x/1.25 oil immersion infinity corrected IOS objective. Working distance 0.36 mm
Plan IOS objectives
BS.8404 Plan PLi 4x/0.10 infinity corrected IOS objective. Working distance 21.0 mm	BS.8410 Plan PLi 10x/0.25 infinity corrected IOS objective. Working distance 5.0 mm	BS.8420 Plan PLi 20x/0.40 infinity corrected IOS objective. Working distance 8.8 mm	BS.8440 Plan PLi S40x/0.65 infinity corrected IOS objective. Working distance 0.66 mm
BS.8460 Plan PLi S60x/0.80 infinity corrected IOS objective. Working distance 0.46 mm	BS.8400 Plan PLi S100x/1.25 oil immersion infinity corrected IOS objective. Working distance 0.36
Plan Phase IOS objectives
BS.8710 Plan Phase PLPHi 10x/0.25 infinity corrected IOS objective. Working distance 5 mm	BS.8720 Plan Phase PLPHi 20x/0.40 infinity corrected IOS objective. Working distance 8.80 mm	BS.8740 Plan Phase PLPHi S40x/0.65 infinity corrected IOS objective. Working distance 0.66 mm	BS.8700 Plan Phase PLPHi S100x/1.25 oil immersion infinity corrected IOS objective. Working distance 0.36 mm
Plan IOS objectives for Materials Science - No cover glass correction
BS.8102 Plan PLMi 2/0.70 infinity corrected IOS objective for bScope Materials Sciences. Working distance 11 mm. No cover glass correction	BS.8105 Plan PLMi 5x/0.12 infinity corrected IOS objective for bright field for bScope Materials Sciences. Working distance 26.1 mm. No cover glass correction	BS.8110 Plan PLMi 10x/0.25 infinity corrected IOS objective for bright field for bScope Materials Sciences. Working distance 20.2 mm. No cover glass correction	BS.8120 Plan PLMi 20x/0.40 infinity corrected IOS objective for bright field for bScope Materials Sciences. Working distance 8.8 mm. No cover glass correction
BS.8150 Plan PLMi S50x/0.70 infinity corrected IOS objective for bright field for bScope Materials Sciences. Working distance 3.7 mm. No cover glass correction	BS.8180 Plan PLMi S80x/0.80 infinity corrected IOS objective for bright field for bScope Materials Sciences. Working distance 1.3 mm. No cover glass correction	BS.8100 Plan PLMi S100x/0.85 infinity corrected IOS objective for bright field for bScope Materials Sciences. Working distance 0.4 mm. No cover glass correction
Plan Fluarex IOS objectives
86.550 Plan Fluarex PLFi 4x/0.15 IOS objective. Working distance 21.6 mm	86.552 Plan Fluarex PLFi 10x/0.35 IOS objective. Working distance 2.9 mm	86.554 Plan Fluarex PLFi 20x/0.65 IOS objective. Working distance 1.5 mm	86.556 Plan Fluarex PLFi S40x/0.85 IOS objective. Working distance 0.60 mm
Condensers
BS.9100 Abbe condenser 1.25 NA without slot . With 32 mm diameter white filter In filter holder	BS.9102 Abbe condenser 1.25 NA with slot for slider, without white filter. Supplied without darkfield slider and without phase contrast sliders.	BS.9105 Swing-out Abbe condenser 0.9/1.25 NA. Without slot for sliders	BS.9170 Slider with darkfield stop for Abbe condenser with slot of bScope. Needs BS.9102 condenser with slot
BS.9194 Slider with phase contrast annuli 40x. Needs BS.9102 condenser with slot	BS.9126 Zernike phase contrast kit with plan PLPHi 10/20/S40x and S100x oil phase contrast IOS infinity corrected objectives, Zernike rotating condenser, telescope and green filter	BS.9148 Alignment telescope for bScope with 30 mm tubes	BS.9149 Alignment telescope for bScope with 23.2 mm tubes
BS.9162 Phase contrast kit with Abbe condenser with slot for slider. Plan PLPHi 10/S40x phase contrast infinity corrected objectives, slider with 10 and 40x annuli, telescope and green	BS.9163 Phase contrast kit with Abbe condenser with slot for slider. Plan PLPHi 20/S100x phase contrast infinity corrected objectives, slider with 20 and 100x annuli, telescope and green	BS.9164 Phase contrast kit with Abbe condenser with slot for slider. Plan PLPHi phase S40x contrast objectives, slider with 40x annuli only, telescope and green filter
Mscellaneous
BS.9515 Metal plain insert for mechanical stage	BS.9518 Glass plain insert for mechanical stage	BS.9577-L Add-on price for left handed mechanical stage	BS.9647 Polarization polarizer 16 mm diameter for slider under bScope head
BS.9728 Polarizer in slider for reflected illumination attachment of Materials Sciences bScope	BS.9706 White 45 mm diameter frosted filter to put on filter holder of lamphouse	BS.9870 Mirror attachment for bScope	BS.9880 Köhler attachment for bScope
BS.9993 NeoLED replacement unit for bScope	BS.9994 Halogen-NeoLED replacement unit for bScope	BS.9993-EK Driving electronics-power supply with wires, potmeter and switch	BS.9900 Aluminium transport case for bScope
AE.9916 Euromex dust cover extra-large. For BioBlue (trino), EcoBlue (trino), BioBlue.Lab, Oxion, bScope, iScope, StereoBlue and NexiusZoom	AE.9919 Nylon bag for bScope, 56(h) x 29(w) x 23(d) cm	AE.1370 Set of 3 rechargeable batteries	AE.5130 Universal SLR adapter with built-in 2x lens for standard 23.2 mm tube. Needs T2 adapter
AE.5168-BS Heating stage with PID controller up to 50°C. Only supplied with a new microscope	AE.5025 T2 ring for Nikon D SLR digital camera	AE.5040 T2 ring for Canon EOS SLR digital camera	AE.5226 Glass fuses 3A 250V, 10pcs for bScope
PB.5155 Microscope slides 76 x 26 mm, ground edges, 50 pieces per pack	PB.5157-W Microscope slides 76 x 26 mm, ground edges. White frosted side, 50 pieces per pack	PB.5157-B Microscope slides 76 x 26 mm, ground edges. Blue frosted side, 50 pieces per pack	PB.5160 Microscope slides 76 x 26 mm with cavity, grinded edges. 10 pieces per pack
PB.5168 Cover glasses 22 x 22 mm, 0.13-0.17 mm, 100 pieces	PB.5165 Cover glasses 18 x 18 mm, 0.13-0.17 mm, 100 pieces	PB.5245 Lens cleaning paper, 100 sheets per pack	PB.5255 Immersion oil, 25 ml. Refraction index n = 1.515
PB.5255.0100 Immersion oil, 100 ml. Refraction index n = 1.515	PB.5274 Iso propyl alcohol 99%, 200 ml	PB.5275 Cleaning kit: lens fluid, lint free lens tissue/paper, brush, air blower, cotton swabs	PB.5276 Microscope maintenance and servicing kit, 16pcs: cleaning brush, 6 pcs screwdriver set, air blower, 3 pcs Allen key, 1.5, 2, 2.5 mm, lens cleaning fluid 20 ml, cleaning cloth 140 x 140 mm, 100 pcs Lens tissue sheets, tube of maintenance grease, 10 ml bottle of oil, packed in a nice toolbox

bScope
Versatile and evolutive!

The well-equipped microscopes of the bScope series are intensively used in secondary schools, universities, small and mid-sized laboratories and for veterinary applications. Apart from excellent ergonomical design, these robust and attractively priced microscopes are available in several configurations with HWF 10x/20 mm eyepieces and objectives for bright field, phase contrast and dark field

The design of the bScope is both ergonomic and evolutive. Height adjustable eyepieces and low stage controls minimize fatigue during long working sessions and therefore providing more comfort for microscopists. Phase contrast and cardioïd mirror dark field models are available. The robust and compact size of the bScope with its Cable Storage System allows more working space, safer operation and easy storage

Extended warranty applies, see "General terms and conditions” for more details (article 10 - Guarantee)

Highlights

• Monocular, binocular and trinocular models

• For education and laboratories

• Robust and attractively priced microscope

• HWF 10x/20 mm eyepieces

• Digital models available

• Reversed nosepiece with slot for polarization filter

• E-plan, E-plan IOS and Plan (phase) IOS objectives

• Rackless integrated X-Y mechanical stage

• Color coded condenser

• Coaxial coarse and fine adjustment with adjustable rack-stop

• 3 W LED illumination with rechargeable batteries

• Cable Storage System

• Integrated carrying grip

• Cardioïd mirror condenser with built-in 3 W LED

• Provided with APL (Antimicrobial Protection Layer)

Specifications

EYEPIECE(S)

• High wide field HWF 10x/20 mm secured eyepiece(s) with 20 mm field of view. The eyepiece of monocular models is supplied with pointer



HEAD

• The bScope is available with a monocular head (45° inclined Ø 23.2 mm tube) or with a Siedentopf type head, 360° rotatable, with 30° inclined Ø 23.2 mm tubes

• Binocular and trinocular models are equipped with a diopter ± 5 adjustment on left eyepiece

• The interpupillary distance is adjustable between 48 to 76 mm

• The models equipped with plan infinity corrected PLi objectives have a unique swiveling system of the eyepiece tubes for ergonomic positioning of both tubes in a high (431 mm) and in a low position (377 mm)

• The trinocular head comes with a Ø 23.2 mm tube, ensuring a maximum of flexibility and has a fixed light path beam splitter (20:80) and generates an erect image

• Models with an integrated USB-2.0 camera are supplied with a 5.0 MP 1/2.5” CMOS sensor with a resolution of 2592 x 1944 pixels

NOSEPIECE
Revolving and reversed ball-beared quadruple or quintuple nosepiece

OBJECTIVES 45 MM PARFOCAL
The state-of-the-art production techniques and multi layer coatings used for the manufacturing of the bScope objectives enables the bScope to be used for the most demanding applications. World class spherical aberration correction and modern CNC and assembly technology ensure the perfect centering of the objectives

• Brightfield models: E-Plan, E-plan IOS infinity corrected, Plan IOS infinity corrected 4x/0.10, 10x/0.25, 20x/0.40, S40x/0.65 and S100x/1.25 oil immersion objectives. Optional 60x/0.85 objective

• Phase contrast models: Plan Phase IOS infinity corrected 10x/0.25, 20x/0.40, S40x/0.65 and S100x/1.25 oil immersion objectives

• Dark field conrast model: E-Plan finity corrected 4x/0.10, 10x/0.25, 20x/0.40, S40x/0.65 and S100x/1.25 oil immersion objectives. The S100x objective is equipped with a built-in iris diaphragm. Optional 60x/0.85 objective

All S40x, S60x and S100x oil immersion objectives are spring loaded. All optics are anti-fungus treated and anti-reflection coated for maximum light throughput

FOCUSING
Double coaxial, low-positioned coarse and fine adjustments with 180 graduations. Precision 1.11 µm, 200 µm per rotation, total travel approximately 19 mm. Supplied with an adjustable rack stop to prevent damage to sample and objectives. The coarse adjustment is equipped with friction control

STAGES

• The bScope is equipped with a scratch resistant 152/197 x 131 mm stage with integrated 75 x 36 mm X-Y rackless mechanical stage, Vernier scale, soft-close removable specimen holder

• The rackless stage has no protruding parts, enables more smooth movements and is safer in use. Low-positioned X-Y control knobs prevent fatique during long working sessions. The bScope can be equipped with a heating stage which can be set up to 50° Celsius by a PID temperature controller. Only available with newly purchased microscopes


CONDENSER FOR BRIGHTFIELD
The standard in height adjustable Abbe N.A. 1.25 condenser for brightfield comes with an iris diaphragm and swing-out filter holder. The condenser is color coded. Optionally available swing-out Abbe condenser (BS.9105)

ZERNIKE CONDENSER FOR PHASE CONTRAST
The in height adjustable Zernike NA. 1.25 phase contrast disc condenser comes with phase annuli for 10/20/S40x and S100x phase contrast objectives, an iris diaphragm, a swing-out filter holder and also a BF position for brightfield contrast. Phase contrast objectives in PLPHi phase contrast versions. Supplied with alignment telescope and green filter

CONDENSER WITH SLIDER(S) FOR  PHASE CONTRAST
The in height adjustable NA. 1.25 simple phase contrast condenser has a free slot for either a slider for 10/S40x phase contrast objectives OR a slider for 20/S100x phase contrast objectives. The condenser has an iris diaphragm and filter holder. The condenser also includes a BF position for brightfield contrast. Phase contrast objectives in PLPHi versions. Supplied with alignment telescope and green filter

CONDENSER FOR DARKFIELD
A state-of-the-art condenser equipped with reflective cardioid mirrors, with an integrated high powered 3 W LED light source. Together with a S100x objective with built-in iris diaphragm this forms a 1000x magnification darkfield solution. The power supply of the 5 W LED light source is built in the microscope. The darkfield condenser can easily be exchanged for a brightfield condenser which is also included

DARKFIELD EQUIPMENT
The BS.1153-EPL/DF is equipped with a darkfield oil immersion cardioïd mirror condenser with a integrated 3 W LED illumination and a plan PL S100x oil immersion objective with built-in iris

POLARISATION
The bScope has an integrated slot above the nosepiece for an optional polarization filter

ILLUMINATION

The microscopes of the bScope are equipped with a 3 W NeoLED adjustable illumination system for increased light output and a 100-240 Vac integrated power supply. On request, rechargeable batteries are also available

NEOLED™ ILLUMINATION
The 3 W adjustable Köhler NeoLED diascopic illumination is powered by an internal 100-240 V power supply making it suitable for worldwide use.The innovative NeoLED design offers larger apertures, allowing the optical system of the bScope microscope to produce images at higher resolutions, very close to the theoretical diffraction limit of the optics. Other benefits of the NeoLED is the low energy consumption, no heating and a long operating lifetime

KÖHLER ILLUMINATION
A Köhler illumination ensures for all infinity corrected IOS models the highest possible contrast and the maximum achievable resolving power. It generates a uniform illumination of the sample and eliminates all interference from dust on lenses and side glare of the light source

The Köhler illumination is optional for non-IOS models


BSCOPE® DIGITAL

• Binocular model

• Integrated 5.0 MP CMOS color USB.2 camera

• 2592 x 1944 pixels

• 7 frames per second (2592 x 1944 pixels)

• 27 frames per second (1280 x 960 pixels)

• ImageFocus Alpha software



CAMERA
The digital bScope microscopes are equipped with a 5.0 MP 1/2.5 inch CMOS USB-2.0 camera, 24 bits color depth, 7 frames per second (2592 x 1944 pixels) or 27 frames per second (1280 x 960 pixels). Dynamic range is 76 db and signal/noise ratio 41 db. Supplied with ImageFocus Alpha software, USB-2.0 cable and a micrometer 1mm/100 calibration slide

SOFTWARE
The capture and analysis ImageFocus Alpha software allows to save images in .jpg, .tif, .bmp or .dicom formats as well as .avi format videos. Measurements and annotations can be done on live or captured images. Compatible with Windows 10 and higher, both 32 and 64 bits configurations. A Mac OS version is also available. Free updates can be downloaded from our website

Further specifications are identical to the analog bScope® models

CORDLESS USE
The optional rechargeable AA batteries turn the bScope into a cordless system

CSS – CABLE  STORAGE SYSTEM
Allows users to easily stow away excess cable length into the back of the instrument during operation and to roll up the power cable for easy storage

CARRYING GRIP
The integrated carrying grip at the back of the microscope ensures safe transportation of the microscope

ANTI-THEFT SLOT
At the back of the microscope a Kensington Security Slot is placed, which can be used to secure the instrument from theft

STORAGE AND TRANSPORTATION

from left to right: BB.9900 - AE.9919 - AE.9916

PACKAGE CONTENT
Smart Styrofoam packaging ensures a low environmental footprint while maintaining maximum safety during transport. Supplied with power cord, dust cover, a spare fuse, white filter, user manual and 5 ml immersion oil.

Phase contrast models are supplied with green filter and alignment telescope. An optional aluminum case can be supplied
