LE.5211 Cold light source

Other Cold light sources
Euromex cold light illuminator EK-1, 100 W, 110V and 230V models available

Model : LE.5211

• Multifunctional cold light sources without fiber light conductor

• Equipped with a 100 W halogen lamp, color temperature 3100 K

• The high luminous flux and special features are ideal for the advanced requirements in Life and Materials Sciences and various industrial applications. And for stereo microscopy

• A large range of fiber optics, adapters and accessories are available

• Dimensions: 215 mm large x 320 mm depth x 115 mm height

• 110 and 230 V mains versions available

LE.5211 Cold light source

For stereo microscopy choosing the right illumination is essential to obtain a perfect image with maximum resolution. Halogen is the traditional light source of choice due to its high light intensity. The LED version almost equals this intensity but has a longer lifespan, less energy consumption and generates less heat

The major advantage of LED illumination is the constant light spectrum at all light intensity levels. The Euromex light sources are suitable for all kind of applications in industry, Life Sciences and Materials Sciences
Cold light source illumination
150 W halogen or 30 W PowerLED

Highlights

• Professional cold light source

• For Materials Science and stereo microscopy

• Halogen 150 W or 30 W PowerLED versions

• Built-in forced air cooling

• Various accessories

• Without fibre optic

Specifications

TECHNICAL SPECIFICATIONS

• Multifunctional cold light sources without fibre light conductor

• The high luminous flux and special features are ideal for the advanced requirements in Life and Materials Sciences, various industrial applications and for stereomicroscopy

• A large range of fibre optics, adapters and accessoiries are available

ILLUMINATION

• The LE.5211 is equipped with a 150 W halogen lamp, color temperature 3100 K

• The LE.5211-LED is equipped with a 30 W PowerLED (brightness equivalent to 120 W halogen), color temperature 6500 K

• The LED versions do not require bulb changing, have longer life time, low energy consumption and produce a white light (daylight)

• No color temperature shifting when dimming (for LED models)


FIBER LIGHT CONDUCTOR
Gooseneck self-sustaining glass fibre light conductor.
Emission angle 65°, with black metal jacket

LE.5213
Single arm fiber light conductor, Gooseneck self-sustaining, 50 cm long, Ø 4 mm

LE.5214
Dual arm fiber light conductor, Gooseneck self-sustaining, 50 cm long, Ø 4 mm

LE.5215
Triple arm fiber light conductor, Gooseneck self-sustaining, 50 cm long, Ø 4 mm

LE.5219
Dual arm fiber light conductor, Gooseneck self-sustaining, 70 cm long, Ø 4 mm

Flexible glass fibre light conductor with black PVC jacket. Emission angle 65°

LE.5216
Single arm flexible fiber light conductor, 100 cm long, Ø 4 mm


LE.5235
Dual arm flexible fiber light conductor, 100 cm long, Ø 4 mm

LE.5218
Single arm flexible fiber light conductor, 100 cm long, Ø 8 mm

MODELS

Accessories for LE.5210, LE.5211 and LE.5211-LED

	LE.5213 Single arm light conductor, Gooseneck self-sustaining, 50 cm long, 4 mm diameter
	LE.5214 Dual arm light conductor, Gooseneck self-sustaining, 50 cm long , 4 mm diameter
	LE.5216 Single arm flexible light conductor, 100 cm long, 4 mm diameter
	LE.5222 Focusing head suitable for focusing lens LE.5224, LE.5228 or filters LE.5223, LE.5229 and LE.5231
	LE.5224 Aspherical focusing lens for mounting in LE.5222 or LE.5228 on LE.5213, LE.5214
	LE.5228 Focusing head with iris diaphragm for mounting on LE.5222
	LE.5229 Polarizing filter
	LE.5231 Conversion filter KB-12/80B for mounting on LE.5222
Economical ring light LED sources
	LE.1974 Ring illuminator with 72 LEDs with adjustable light intensity. External power supply 110-240 Vac / 12 Vdc (50/60 Hz). With segment controller. Brightness of 21,000 Lux at 100 mm distance and color temperature of 6500 K. Mounting for stereo head with diameter from 25 to 61 mm
	LE.1973 Ring illuminator with 144 LEDs with adjustable light intensity. External power supply 100-240 Vac / 12 Vdc (50/60 Hz). With segment controller. Brightness of 23,000 Lux at 100 mm distance and color temperature of 6500 K. Mounting for stereo head with diameter from 25 to 61 mm
	LE.1975 Polarizing ring illuminator with 16 High Power white LEDs with adjustable light intensity. External power supply 100-240 Vac / 24 Vdc 220 mA 4.5W (50/60 Hz). Brightness of 44.000 Lux at 100 mm distance and color temperature of 6000-6500 K. Mounting for stereo head with diameter from 35 to 62 mm
Professional ring light 48 LED sources
	LE.1980 Industrial LED ring light with 48 leds, diam. 45mm/90mm with connection for analog controller LE.1992
	LE.1981 Industrial LED ring light with 48 leds, diam. 45mm/90mm with connection for digital segment controller LE.1993
	LE.1984-050 Fresnel lens working distance 40-80mm for LE.1980/LE.1981
	LE.1984-100 Fresnel lens working distance 80-150mm for LE.1980/LE.1981
	LE.1984-200 Fresnel lens working distance 150-240mm for LE.1980/LE.1981
	LE.1984 Diffuser for LE.1980 / LE.1981
	LE.1985 Protection glass for LE.1980 / LE.1981
	LE.1987 Polarizer for LE.1980 / LE.1981
	LE.1988 Rotatable polarizer for LE.1980 / LE.1981
Miscellaneous
	AE.5212 Glass fuses 1.25 A 250 V, 10 pieces
	AE.5227 Glass fuses 1 A 250 V, 10 pieces
	SL.1864 Spare fluorescence ring-shaped lamp
	SL.5197-230 Spare bulb 30 W 230 V
	SL.5208 Halogen Spare bulb 12V 20W GU4 Nominal 4000 hrs 13,90
	SL.5211 Spare LED assembly for LE.5211-LED
	SL.5219 Halogen spare bulb 12V 100 W MR16 Nominal 50 hrs
	SL.5230 Long life halogen bulb 12V 100 W MR16 Nominal 1500 hrs
	SL.5235 Halogen spare bulb 15V 150 W MR16 Nominal 50 hrs
	SL.5240 Long life halogen bulb 15V 150 W MR16 Nominal 500 hrs

Downloads

  LE.5211_product_datasheet_English
